Features

• Operating Instruction: 1. This model is fitted with at 24 hour timer which has 96 segments around its circumference, each segment being equivalent to 15 minutes of time. 2. It is possible to set the time and duration of the period(s) that it is desired the heater will operate in any 24 hour period. 3. The center of the timer has a 3 position switch. - in the central position (denoted by the clock symbol) the timer will switch the heater on and off at times set by the segments. - the position denoted by the “I”, is a timer override position. The timer will continue to run but power will be fed continuously to the heater. The enables the heater to be on all the time if required. - in the position denoted by the “O” the timer to run but no power is fed to the heater. 4. To set the timer, ensure teh slider switch on the timer is in the central position next to the clock symbol. 5. Rotate the outer ring of the timer in a clockwise direction until the current time lined up with the arrow pointer. 6. Set the time that the heater is required to run by pulling the segments around the outer ring forward appropriate to the running period(s) required. 7. When set, the heater will operate each day during the times programmed. Note, the heater must always be plugged into the power socket, the element switches must be in the on position and the thermostat must be suitably set to ensure the heater will come on. 8. If the heater is required to run continuously the side switch on the timer should be set to the “I” position. If it is subsequently required to revert back to the timer operation, the slide switch on the timer should be set to the central (clock) position.
